Shelf Rack Post Roll Forming Machine
Specifications:
| Formed Material | CR,HR Sheet;Galvanized Sheet | Thickness: 1.2-3.2mm |
|---|---|---|
| Strength | ≤350 Mpa | |
| Coil internal diameter | 500,600 MM | |
| Coil weight | 5 Ton | |
| Main Body | Roller station | 18 TO 22 Raws (As per Requirement) |
| Diameter of shaft | 65mm solid shaft | |
| Material of rollers | D2 quenching treatment | |
| Machine body frame | Mild Steel welded | |
| Drive | Gear Drive | |
| Dimension(L*W*H) | 6000x1000x1200 mm (Customize) | |
| Weight | Approx 6 tonne | |
| Decoiler | Hydraulic Automatic/Manual decoiler | hydraulic/manual decoiler with higher speed |
| Cutter | Automatic | cr12mov material, no scratches, no deformation |
| Power | Motor Power | 7.5KW |
| Hydraulic system power | 5.5KW | |
| Control system | PLC | Automatic production of the whole machine. Can set batch, length, quantity, etc. |
| Forming Speed | 10-12m/min(customized) | Speed is adjustable according to customer’s request |
